RF-Elements, Carrier Class Sector, 2.4GHz, 14dBi 2x2 HV, SEC-CC-2-14

RF-Elements, Carrier Class Sector, 2.4GHz, 14dBi 2x2 HV, SEC-CC-2-14

RF Elements
SKU:
SEC-CC-2-14
$130.00
Current Stock:

Out of stock, but we may be able to make magic happen!

Contact Us
Description



RF-Elements, Carrier Class Sector, 2.4GHz, 14dBi 2x2 HV, SEC-CC-2-14

RF elements CARRIER CLASS Sectors are addressing customer requirements for exceptional RF performance, co-location noise resistance, ease of installation and cost efficiency. Our antennas feature an innovative patent pending Back-Shield™ system of frequency selective re sectors that are incorporated into the antenna structure to attenuate side lobes and backside near field radiation.All CARRIER CLASS Sectors are designed with independent horizontal and vertical polarization antenna elements for unmatched RF performance.

  • Frequency Range 2400 - 2485 MHz
  • Gain13.8 dBi
  • Polarization Dual Linear H + V
  • Azimuth Beam Width -3 dBH 75° / V 69°
  • Elevation Beam Width -3 dBH 14.5° / V 14°
  • Azimuth Beam Width -6 dBH 108° / V 100°
  • Elevation Beam Width -6 dBH 20° / V 19°
  • Front-to-Back Ratio (Min) 24 dB
Product Downloads
RF-Elements, Carrier Class Sector, SEC-CC-2-14, Datasheet
